Ionya H 19
Ionya H 22
29 kW
Pellet thermo stove
Ionya H 19
Ionya H 22
Pellet-burning stoves featuring “Magic” glass – completely black, allowing the flame to be seen but concealing the firebox when the stove is off, ensuring a consistently elegant design.
• steel structure and combustion chamber• ceramic ignitor
• smoke outlet Ø 8 cm rear
• double closing door
• built-in hydraulic kit
• easy to install, with all plumbing fitted on board
• display on top
• daily/weekly program
• Built-in Wi-Fi (APP EK Home)
AVAILABLE MODELS
• white steel• black steel
• dove gray steel
Optional
• Kit P (pre-assembled hydraulic kit)
• Control unit with display (for Kit P)
• NTC water sensor
• Accessories
| Technical Data |
Ionya H 19 min/max |
Ionya H 22 min/max |
|
| width | cm | 57 | 57 |
| depth | cm | 64,5 | 64,5 |
| height | cm | 124 | 124 |
| useful output | kW | 5,5-18,7 | 5,5-22,8 |
| useful output to the water | kW | 14,8 | 18,5 |
| efficiency | % | 90,5 | 90,1 |
| fuel consumption | kg/h | 1,3-4,3 | 1,3-5,3 |
| tank capacity | kg | 25 | 25 |
| autonomy | h | 6-19 | 5-19 |
| water content | l | 13 | 13 |
| Ø combustion product outlet | cm | 8 | 8 |
| Ø external air intake | cm | 5 | 5 |
| total weight | kg | 190 | 190 |
| vol. that can be heated | m³ | 485 | 595 |
